4t/h Circulating Fluidized Bed Boiler

  • Overview
  • Advantage
  • Parameter

Circulating fluidized bed combustion technology has the characteristics of high efficiency, clean, and low temperature, it is developed and promoted in recently years. Sitong Boiler takes advantages of high efficiency external circulationg cyclone combustion technology, has the characteristics of high thermal efficiency, high desulfurization rate, compact structure, and easy operation. The boiler could be used for different industrial production and electric generation, it is the ideal alternative heating equipment to the conventional boilers.


CFB boiler adopts fluidized combustion technology, the main structures includes combustion furnace (densen region and Dilute region) and circulating system (high temperature gas-solid separator and material returning system). The combustion system is consisted of furnace, ventilation device and winde chambers. Ventilation device has two types: one is air nozzles type, another one is tight hole types. There are many types wind chambers, the most frequently used is uniform-pressure wind chamber.


Technical Advantages


1.Burn Different Types Solid Fuels

The temperature in furnace is 850℃~950℃, the fuel particle could reach to furnace temperature and burn rapaidly. Thus, CFB boiler could burn different type solid fuels without any auxiliary fuels.


2. High Combustion Efficiency

The fuel is mixed with a large amount of high temperature bed fuels and burn rapidly, and has high combustion rate. The unburned particles are returned to furnace for circulating cumbustion by cyclone separator, lengthen combustion period, and increase combustion efficiency.


3. Excellent Desulfurization Effect

Desulfurization process is processed under the optimum reation temperature in furnace, and the circulating system could lengthen the residence time of desulfurizer in boiler, also, the desulfurizer particle size is small as 0.1mm, the reaction contact area with fuel is large, so the desulfurization rate is high.


4. Low NOx Emission

The furnace temperature is keep at 850℃~950℃, the temperature is relatively low, so the NOx emission is less. Otherwise, CFB boiler adopts zoning air supply and zoning combustion, the fuel could burn sufficiently, low NOx emission.


5. High Heat Load of Furnace Cross Section

Strong mixing and fast heat transfer in furnace, the furnace cross section has high heat load (around 3~5MW/㎡).


6. Slag Could be Utilizated Comprehensively

The fuel is combusted under low temperature, and the high combustion efficiency makes slag has low carbon content, also, there are large amount of calcium oxide and calcium sulfate, could used for cement and brick, etc.



4ton CFB Boiler Parameter


Model: SHX 4-1.25-S

Boiler Capacity: 4t/h

Boiler Pressure: 1.25Mpa

Feed Water Temperature: 104℃

Design Thermal Efficiency: 81%~84%

Exhaust Smoke Temperature: 155℃

Overall Dimension: 5300*3255*6400 (L*W*H)


Technical Advantages



1.Burn Different Types Solid Fuels

The temperature in furnace is 850℃~950℃, the fuel particle could reach to furnace temperature and burn rapaidly. Thus, CFB boiler could burn different type solid fuels without any auxiliary fuels.


2. High Combustion Efficiency

The fuel is mixed with a large amount of high temperature bed fuels and burn rapidly, and has high combustion rate. The unburned particles are returned to furnace for circulating cumbustion by cyclone separator, lengthen combustion period, and increase combustion efficiency.


3. Excellent Desulfurization Effect

Desulfurization process is processed under the optimum reation temperature in furnace, and the circulating system could lengthen the residence time of desulfurizer in boiler, also, the desulfurizer particle size is small as 0.1mm, the reaction contact area with fuel is large, so the desulfurization rate is high.


4. Low NOx Emission

The furnace temperature is keep at 850℃~950℃, the temperature is relatively low, so the NOx emission is less. Otherwise, CFB boiler adopts zoning air supply and zoning combustion, the fuel could burn sufficiently, low NOx emission.


5. High Heat Load of Furnace Cross Section

Strong mixing and fast heat transfer in furnace, the furnace cross section has high heat load (around 3~5MW/㎡).


6. Slag Could be Utilizated Comprehensively

The fuel is combusted under low temperature, and the high combustion efficiency makes slag has low carbon content, also, there are large amount of calcium oxide and calcium sulfate, could used for cement and brick, etc.



4ton CFB Boiler Parameter


Model: SHX 4-1.25-S

Boiler Capacity: 4t/h

Boiler Pressure: 1.25Mpa

Feed Water Temperature: 104℃

Design Thermal Efficiency: 81%~84%

Exhaust Smoke Temperature: 155℃

Overall Dimension: 5300*3255*6400 (L*W*H)


4ton CFB Boiler Parameter


Model: SHX 4-1.25-S

Boiler Capacity: 4t/h

Boiler Pressure: 1.25Mpa

Feed Water Temperature: 104℃

Design Thermal Efficiency: 81%~84%

Exhaust Smoke Temperature: 155℃

Overall Dimension: 5300*3255*6400 (L*W*H)
